Industrial Gigabit Smart Managed Switch
DIS-200G-12S
- Product Status: Live
- 10 x 10/100/1000Base-T ports, 2 x SFP ports
- RJ-45 Console port
- Easy-to-control management interfaces and security
- Withstands severe temperatures
- Compliant with vibration, shock, free-fall testing
Where to buy
Features
![](/au/en/-/media/product-pages/dis/common/managedcustomization.png?mh=300&h=120&w=120&la=en-AU&hash=42B954681C65E9D83361F86884DA1C61)
Featuring management interfaces, including an industry-standard CLI, and Web-based UI, the DIS-200G Serie is easy to manage and provides the controls to help protect and shape your network.
![](/au/en/-/media/product-pages/dis/common/gigabitconnectivity.png?mh=300&h=120&w=120&la=en-AU&hash=C3DBDEB45594FDE0DBE51A95608BFF7F)
Designed with 10 x 10/100/1000BaseT ports and 2 x SFP ports to suit a range of devices and network layouts.
![](/au/en/-/media/product-pages/dis/common/officiallycertified.png?mh=300&h=120&w=120&la=en-AU&hash=510D9235917D183D69336B5CDED15CB8)
Certifications for vibration, shock, free-fall, electromagnetic, and high-capacity 6 kV surge protection on all copper ports to maximise network uptime in harsh deployment environments.
![](/au/en/-/media/product-pages/dis/common/temperatures.png?mh=300&h=120&w=120&la=en-AU&hash=D66741083F70EA5B354A52BCE2577E25)
Operates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +65°C.
![](/au/en/-/media/product-pages/dis/common/highavailability.png?mh=300&h=120&w=120&la=en-AU&hash=2B3C0C459FEF3FCE1720017197BFF1DB)
ERPS quick failover recovery for ring topologies that ensures minimal downtime and avoids any loss of data in mission-critical deployment settings.
![](/au/en/-/media/product-pages/dis/common/strong.png?mh=300&h=120&w=120&la=en-AU&hash=1B2787552BB021F95A5B53F95697DF1E)
The tough housing has been created to keep your network protected and reliably rugged. That’s why every DIS-switch comes with a 5-year D-Link warranty.
![](/au/en/-/media/product-pages/dis/common/easy_management.png?mh=300&h=120&w=120&la=en-AU&hash=62659F557F30047A6EE7FD3A60536FFD)
![](/au/en/-/media/product-pages/dis/common/fanlessdesign.png?mh=300&h=120&w=120&la=en-AU&hash=55CC7D9A0656A8AEE97087CCF8A36172)
With no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat.
![](/au/en/-/media/product-pages/dis/common/fastdeployment.png?mh=300&h=120&w=120&la=en-AU&hash=356B4459E0E4FBBD07F20F378D692C8E)
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.
![](/au/en/-/media/product-pages/dis/common/discreetsize.png?mh=300&h=120&w=120&la=en-AU&hash=25060D4A1108F58F85FB6C437290E9B9)
Small but mighty. To make the most of cabinet space, it measures: 48 x 210 x 171.2 mm.
Related Products
![](/au/en/-/media/product-pages/dis/100g-series/dis_100g_5sw_leftsideangle.png?h=100&w=66&la=en-AU&hash=131AF69DF8DAFB1D2C2E4F94352CE5AB)
![](/au/en/-/media/product-pages/dis/200g-series/dis200g12psa1image-lside2.png?h=100&w=59&la=en-AU&hash=37D7CDF274B6761A25BB7C85F78B5C55)
![](/au/en/-/media/product-pages/dis/300g-series/dis_300g_12sw_leftsideangle.png?h=100&w=68&la=en-AU&hash=3006122FEEDBEA750C7EF1F7AF44806D)
Specs
Type
|
Industrial Smart managed |
---|---|
Number of ports
|
5 to 14 ports |
Layer
|
Layer 2 |
Main type of ports
|
1000BASE-T Gigabit Ethernet |
Type of uplink ports
|
SFP |
Switching capacity
|
24 Gbps |
Fanless
|
Supported
|
802.3az Energy-Efficient Ethernet support
|
Supported
|
Form Factor
|
DIN rail |
Housing
|
Metal |
Jumbo frame
|
Supported
|
Cable diagnostics
|
Supported
|
Environmental
|
Free Fall: IEC60068-2-32 Shock: IEC60068-2-27 Vibration: IEC60068-2-6 |
MAC address
|
8K |
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
Ethernet ring protection switching (ERPS)
|
Supported
|
Link aggregation
|
802.3ad |
VLAN group (max static)
|
128 |
VLAN type
|
GVRP Port-based |
Advanced VLAN
|
Asymmetric VLAN Auto Surveillance VLAN Voice VLAN |
Number of QoS queues per port
|
4 |
Encryption protocol supported
|
SSH |
802.1X access control
|
Supported
|
RADIUS/TACACS+ authentication
|
Supported
|
SNMP (v1/v2c/v3)
|
Supported
|
LLDP
|
Supported
|
