10-Port Gigabit PoE Switch

DGS-1010MP

  • Product Status (Revision v100): Live
  • High-speed networking with eight 10/100/1000 Mbps PoE Ethernet access ports
  • One Gigabit Ethernet and one SFP uplink port for uplink connections
  • Plug-and-Play installation
  • Store-and-forward switching maximizes network performance
  • Compact and silent design
  • Green Technology

Download the datasheet.

Where to buy

Effortless Gigabit Network Expansion

The D-Link DGS-1010MP 10-Port Gigabit PoE Switch is an ideal solution for small offices and enterprise environments looking to expand the network with Gigabit connectivity. With eight Power over Ethernet (PoE) ports, you can power more PoE-capable cameras, access points, and VoIP phones using standard Ethernet cabling. And its one Gigabit Ethernet and one SFP uplink port allow for additional connections to storage or an uplink network.

PoE

The DGS-1010MP features eight 10/100/1000BASE-T ports that support the IEEE 802.3at Power over Ethernet (PoE) standard. This allows devices to be installed in locations without any power outlets, saving on installation costs and reducing the time it takes to install new devices.

Superior Performance

The switch features one Gigabit Ethernet and one SFP uplink port for high-speed connections to remote storage or for long distance fiber connections to an uplink network. It also incorporates store-and-forward switching to maximize network performance while minimizing packet loss during data transmission.

Compact & Silent Design

The DGS-1010MP has a compact 11” design, so that it can be deployed in any easily accessible location on the work floor, allowing you to power a set of PoE-powered devices while avoiding excessive cable clutter. The switch also has a fanless design, guaranteeing a quiet working environment.

Green Technology

The DGS-1010MP supports IEEE 802.3az Energy-Efficient Ethernet (EEE), reducing power consumption of the switch when network utilization is low and minimizing operating costs during periods of inactivity. By using EEE-compliant devices with the DGS-1010MP, organizations can noticeably reduce power consumption by having the switch automatically put ports into sleep mode when they are not being used.

Dimensions
280 x 180 x 44 mm(11.02 x 7.08 x 1.73 in)
FAN
Fanless
Humidity
Operating: 0% - 95% RH
Storage: 0% - 95% RH
Interfaces
1 x 1000Base-T
1 x 1000M SFP
8 x 1000Base-T PoE
Auto MDI/MDIX
Maximum Forwarding Rate
14.88 Mpps
Maximum Power Consumption
PoE on: 133.8W
Operating Altitude
2000 m
Packet Buffer Size
1.5Mbits
PoE Power Budget
125 W
Power Input
100 to 240 V AC
Switching Capacity
20 Gbps
Temperature
Operating: 0 ~ 40 °C
Storage: -10 - 70 ˚C
Weight
1.84 kgs

Support

Version Date Type File Size
DataSheet - PDF 1.69mb Download
