4G LTE M2M Router

DWM-312W

  • Product Status ($name): Live
  • LTE speeds up to 150Mbps
  • Fast Ethernet for broad compatibility
  • Dual-SIM capabilities
  • Plug-and-play with Ethernet interface
  • Support for IPSec, PPTP, L2TPv2, GRE, and OpenVPN tunneling
  • SNMP management support for rapid deployment
  • TR-069 CPE WAN Management Protocol
  • Tolerates a wide range of operating temperatures and humidity
  • Sturdy wall-mounts for flexible placement

Download the datasheet.

Where to buy

Made for M2M

The D-Link DWM-312W 4G LTE M2M Router features a dedicated fast Ethernet port and Dual-SIM 4G LTE mobile broadband for maximum redundancy and flexibility to power your Machine-to-Machine (M2M) applications. Powerful VPN tools and advanced remote management combined with ease of use make this M2M router ideal for large-scale and individual deployments.

Maximum Speeds for Mixed Network Environments

Configurable Dual-SIM fallback means the 4G LTE M2M Router provides reliable and flexible connections in your mixed network environments. Get the speed you need for fast responsive Internet access with downlink speeds of up to 150Mbps and uplink speeds up to 50Mbps.

Reliable High-Speed VPN

The DWM-312W 4G LTE M2M Router’s integrated VPN client and server is compatible with almost any VPN policy. The router’s hardware engine can support and manage multiple VPN confgurations. It supports IPSec, GRE, and OpenVPN protocols and handles passthrough traffic as well. Advanced VPN confguration settings include multiple encryption options, key management, negotiation modes, and VPN authentication using an internal user database.

Toughs it Out in Any Environment

The industrial-strength casing provides reliable high-speed connectivity in extreme conditions. With its corrosion-resistance and robust temperature and humidity tolerances, this router is ready for the most demanding M2M applications in virtually any environment.

Network Agility for Enterprise IoT Management

D-Link offers the latest advanced EaaS (Edge as a Service) cloud computing platform to enable flexible, secure and low latency networks for mission critical operations.

With fast, flexible deployment and having full control and visibility over your network, the D-ECS D-Link Edge Cloud Solution platform offers extensive functionality enabling device management, traffic analytics, security, cost-management and more.

Learn More
Advanced Features
L2TP/PPTP/IPSec VPN Client/Server modes
Firmware over the air (FOTA) upgrades
QoS engine (Quality of Service)
SNMP Support
TR-069 CPE WAN Management Protocol
Web-based UI
Data Throughput
EDGE up to 236.8 Kbps
HSPDA-DC up to 42 Mbps down / 5.76 Mbps up
LTE Throughput
Up to 150 Mbps down / 50 Mbps up
Dimensions
134 x 76 x 32 mm (5.28 x 2.99 x 1.26 in)
Interfaces
1 x 10/100/1000 Fast Ethernet LAN port
1 x 10/100/1000 Fast Ethernet WAN/LAN port
1 x 5.5 mm DC input
3 x SMA antenna connectors: 2 LTE+1 Wi-Fi
DI/DO/Grounding ports
Dual standard 2FF SIM slot
Power Feature
12 V / 1 A adapter
Flexible input: DC 9V / 2A ~ 36V / 0.7A
Standards
IEEE 802.3i
IEEE 802.3u
Weight
500 g

Support

Version Date Type File Size
Datasheet - PDF 1.52mb Download
