Description
The DGS-3324SR is the first in a new series of “Next Generation” high performance stackables from D-Link Systems. The DGS-3324SR blends many features typically found in more expensive chassis based solutions, (high density, hot swap, redundant power options, and high performance) with the price and flexibility of a stackable.
D-Link’s xStack Switches Series is a set of “Next Generation” high performance stackable switches that deliver high scalability, wire-speed Gigabit performance, high availability, integrated 10-Gigabit stacking, redundant power option, and support for stacking in a “ring” or “star” topology (requires DGS-3324SRi as stacking master). The DGS-3324SR blends many features typically found in more expensive chassis based solutions with the price and flexibility of a stackable switch. When stacked in a ring configuration, it provides up to 384 Gigabit ports. It also stacks with the other xStack™ Series switches including the DGS-3324SRi, DXS-3350SR, and DXS-3326GSR to provide unprecedented flexibility in a switch stack environment.
Performance
The xStack™ DGS-3324SR is a 24-Port 10/100/1000BASE-T Managed Stackable Multilayer Switch with (4) combo ports supporting SFP transceivers. It has an 88Gbps switching capacity and supports dual integrated 10-Gigabit stacking ports for up to 40Gbps of full-duplex stacking bandwidth.
High Availability
Its architecture supports stacking of up to 12 units* using the integrated rear 10-Gig stacking ports in a “Shortest-Path, Fail-Safe” ring configuration. Each unit also supports an optional redundant power supply (DPS-500). Other features include support for 802.3ad Link Aggregation, 802.1d Spanning Tree, 802.1w Rapid Spanning Tree, and 802.1s Multiple Spanning Tree for increased network reliability and availability.
Network Management
An extensive set of network management features is supported including console CLI, telnet, web, SNMPv1/v2/v3, RMON, TFTP, Port Mirroring, BootP, and DHCP. The switch can also be easily managed using D-Link’s SIM (Single IP Management) Clustering technology for a virtual stack of up to 32 switches. It also provides a variety of advanced traffic management options including 802.1x, Bandwidth Control, Broadcast Rate Limiting, and support for IGMP Snooping v1/v2/v3.
Advanced Enterprise Features
The xStack™ DGS-3324SR implements a robust and consistent set of QoS/CoS, VLAN, and Security features. It supports 8 priority queues for 802.1p/ToS/DiffServ, with classification and marking based on MAC SA/DA, IP SA/DA, and/or TCP/UDP port numbers. Layer 3 dynamic routing protocols include RIPv1/v2, OSPFv2, PIM-DM, PIM-SM, DVMRP, and VRRP. Security features include 802.1x Port Based Authentication 802.1x MAC Based Authentication , and Access Control Lists based on MAC address, IP address, TCP/UDP port numbers, and IPv6 address and traffic class. The DGS-3324SR also has extensive support for GARP/GVRP, 802.1q, 802.1v IPv6 VLAN, and port based VLANs for up to 4000 groups.
The xStack™ DGS-3324SR is the latest example of D-Link’s continued commitment to our channel partners and customers to be the industry leader in delivering cost-effective, reliable, high performance, feature-rich switches.
* Maximum number of units in a stack may vary depending on model and configuration.
The DGS-3324SR is the first in a new series of “Next Generation” high performance stackables from D-Link Systems. The DGS-3324SR blends many features typically found in more expensive chassis based solutions, (high density, hot swap, redundant power options, and high performance) with the price and flexibility of a stackable.
D-Link’s xStack Switches Series is a set of “Next Generation” high performance stackable switches that deliver high scalability, wire-speed Gigabit performance, high availability, integrated 10-Gigabit stacking, redundant power option, and support for stacking in a “ring” or “star” topology (requires DGS-3324SRi as stacking master). The DGS-3324SR blends many features typically found in more expensive chassis based solutions with the price and flexibility of a stackable switch. When stacked in a ring configuration, it provides up to 384 Gigabit ports. It also stacks with the other xStack™ Series switches including the DGS-3324SRi, DXS-3350SR, and DXS-3326GSR to provide unprecedented flexibility in a switch stack environment.
Performance
The xStack™ DGS-3324SR is a 24-Port 10/100/1000BASE-T Managed Stackable Multilayer Switch with (4) combo ports supporting SFP transceivers. It has an 88Gbps switching capacity and supports dual integrated 10-Gigabit stacking ports for up to 40Gbps of full-duplex stacking bandwidth.
High Availability
Its architecture supports stacking of up to 12 units* using the integrated rear 10-Gig stacking ports in a “Shortest-Path, Fail-Safe” ring configuration. Each unit also supports an optional redundant power supply (DPS-500). Other features include support for 802.3ad Link Aggregation, 802.1d Spanning Tree, 802.1w Rapid Spanning Tree, and 802.1s Multiple Spanning Tree for increased network reliability and availability.
Network Management
An extensive set of network management features is supported including console CLI, telnet, web, SNMPv1/v2/v3, RMON, TFTP, Port Mirroring, BootP, and DHCP. The switch can also be easily managed using D-Link’s SIM (Single IP Management) Clustering technology for a virtual stack of up to 32 switches. It also provides a variety of advanced traffic management options including 802.1x, Bandwidth Control, Broadcast Rate Limiting, and support for IGMP Snooping v1/v2/v3.
Advanced Enterprise Features
The xStack™ DGS-3324SR implements a robust and consistent set of QoS/CoS, VLAN, and Security features. It supports 8 priority queues for 802.1p/ToS/DiffServ, with classification and marking based on MAC SA/DA, IP SA/DA, and/or TCP/UDP port numbers. Layer 3 dynamic routing protocols include RIPv1/v2, OSPFv2, PIM-DM, PIM-SM, DVMRP, and VRRP. Security features include 802.1x Port Based Authentication 802.1x MAC Based Authentication , and Access Control Lists based on MAC address, IP address, TCP/UDP port numbers, and IPv6 address and traffic class. The DGS-3324SR also has extensive support for GARP/GVRP, 802.1q, 802.1v IPv6 VLAN, and port based VLANs for up to 4000 groups.
The xStack™ DGS-3324SR is the latest example of D-Link’s continued commitment to our channel partners and customers to be the industry leader in delivering cost-effective, reliable, high performance, feature-rich switches.
* Maximum number of units in a stack may vary depending on model and configuration.
Specs
Technical Specifications
Hardware
Device Ports
Unit Stacking
Port Standard/Function Support
SFP (Mini GBIC) Support
Diagnostic LEDs
Per device:
Per 10/100/1000BASE-T port:
Per SFP port:
Per stacking port:
7-Segment Display
Software
IP Routing
* Feature available in next firmware upgrade
Priority Queues (CoS)
Traffic Classification (CoS)
Can be based on user-definable application types:
Network Access Security
Spanning Tree Protocol
* 802.1w available in next firmware release
IP Multicast
* Function supported in future firmware upgrade
MultiLink Trunking (MLT)
Enables grouping of links between the switch and another switch or a server to provide higher bandwidth of up to 8 Gigabit ports with active redundant links. A multi-link is defined as trunked ports spanning multiple units of the stack for fail-safe connectivity to mission-critical servers and the network center.
* Available in future firmware upgrade
Performance
Switch Fabric
Transmission Method
MAC Address Table
MAC Address Learning
IP Address Learning
Packet Filtering/Forwarding Rates (half duplex)
RAM Buffer
Jumbo Frame
Configuration & Management
Management Support
* SNMP v.3 available in next firmware release
MIBs
RMON Groups
IP Number Self-identification
Firmware Upgrade
Console Port
Physical & Environmental
Power Input
Redundant Power Backup Support
Power Consumption
Ventilation
Dimensions
Weight
Operating Temperature
Storage Temperature
Humidity
Emission (EMI)
Safety
Ordering Information
Gigabit Stackable Layer 3 Switch
DGS-3324SR
Optional Gigabit Stacking Master Layer 3 Switch
DGS-3324SRi
Optional SFP (Mini GBIC) Transceiver
DEM-310GT
DEM-311GT
DEM-314GT
DEM-315GT
Optional Redundant Power Supply
DPS-500
DPS-800
DPS-900
Hardware
Device Ports
- 24 auto-sensing 10/100/1000BASE-T ports (front panel)
- 4 combo SFP (Mini GBIC) ports (front panel)
- 2 10Gbps stacking ports (rear panel)
- 1 RS-232 console port (front panel)
Unit Stacking
- Ring architecture: 12 units per stack
- Star architecture: 6 units per stack + 1 DGS-3324SRi Stacking Master
Port Standard/Function Support
- IEEE 802.3 10BASE-T/802.3u 100BASE-TX/802.3ab 1000BASE-T
- ANSI/IEEE 802.3 NWay auto-negotiation
- IEEE 802.3x Flow Control
- Auto MDI/MDIX
- Port mirroring
SFP (Mini GBIC) Support
- IEEE 802.3z 1000BASE-LX (DEM-310GT transceiver)
- IEEE 802.3z 1000BASE-SX (DEM-311GT transceiver)
- IEEE 802.3z 1000BASE-LH (DEM-314GT transceiver)
- IEEE 802.3z 1000BASE-ZX (DEM-315GT transceiver)
Diagnostic LEDs
Per device:
- Power On/Off
- Master
- Console (login/POST status)
- RPS in use/not in use
Per 10/100/1000BASE-T port:
- 1000Mbps speed, 10/100Mbps speed
- Link/Activity
Per SFP port:
- Link/Activity
Per stacking port:
- Link/No Link
7-Segment Display
- To display unit ID in the stack
Software
IP Routing
- IP v4 support
- IP Fragmentation support
- IP multi-netting
- Routing protocols supported:
- Static routing
- RIP-1, RIP-2
- OSPF v.2
- IEEE 802.1Q Tagged VLAN
- GARP/GVRP
- Asymmetric VLAN *
- Number of VLANs: 4K static VLANs (max.)
- Supports multiple IPs per VLAN *
* Feature available in next firmware upgrade
Priority Queues (CoS)
- Standard: IEEE 802.1p
- Number of queues: 8
Traffic Classification (CoS)
Can be based on user-definable application types:
- TOS
- Diffserv (DSCP)
- Port-based
- MAC address
- IP address
- TCP/UDP port number
Network Access Security
- Port security features
- 802.1x user authentication
- Port-based access control
- MAC-based access control *
- RADIUS client
- Multi-layer ACL based on:
- VLAN
- MAC address
- IP address Protocol type
- TCP/UDP port number
- 802.1p
- Diffserv (DSCP)
- Other authentication protocols supported:
- SSH2 *
- TACACS *
- TACACS+ *
- SSL *
Spanning Tree Protocol
- 802.1D Spanning Tree compatible
- 802.1w Rapid Spanning Tree *
* 802.1w available in next firmware release
IP Multicast
- IGMP Snooping
- IGMP v.2
- DVMRP
- PIM Dense mode
- PIM Sparse mode *
* Function supported in future firmware upgrade
MultiLink Trunking (MLT)
Enables grouping of links between the switch and another switch or a server to provide higher bandwidth of up to 8 Gigabit ports with active redundant links. A multi-link is defined as trunked ports spanning multiple units of the stack for fail-safe connectivity to mission-critical servers and the network center.
- Supports up to 32 trunking groups; up to 8 ports per group
- Operation mode: load sharing
- 802.3ad compatible Link Aggregation static mode
- 802.3ad compatible Link Aggregation (LACP) *
* Available in future firmware upgrade
Performance
Switch Fabric
- 88Gbps (32Mpps)
Transmission Method
- Store-and-forward
MAC Address Table
- 16K entries per device
MAC Address Learning
- Dynamic entries: automatic update
- Static entries: user-defined
IP Address Learning
- Dynamic entries: automatic update
- Supports Delete of individual IP addresses by dynamic learning
Packet Filtering/Forwarding Rates (half duplex)
- 1,488,100 pps per port (max.)
RAM Buffer
- 2MB per device
Jumbo Frame
- Up to 9,216 bytes
Configuration & Management
Management Support
- SNMP v.1, v.2c, v.3 *
- Web-based management
- Web GUI traffic monitoring
- Web-based MAC address browsing
- CLI (command line interface)
- RMON monitoring
- Telnet server
- SYSLOG
* SNMP v.3 available in next firmware release
MIBs
- MIB-II (RFC 1213)
- Bridge MIB (RFC 1493)
- RMON MIB (RFC 1757)
- 802.1p Priority Queues (RFC 2674)
- 802.1Q VLAN MIB (RFC 2674)
- IGMP MIB (RFC 2833)
- If MIB (RFC 2233)
- Ethernet-like MIB (RFC 1643)
- RIP MIB (RFC 1724)
- OSPF MIB (RFC 1850)
- CIDR MIB (RFC 2096)
- D-Link enterprise MIB
RMON Groups
- 1, 2, 3, 9 (Alarm, Statistics, History, Event)
IP Number Self-identification
- Through DHCP client, Bootp client
Firmware Upgrade
- TFTP
Console Port
- DB-9 RS-232 DCE
Physical & Environmental
Power Input
- 100 to 240 VAC, 50~60 Hz
- Internal power supply
Redundant Power Backup Support
- Connector to connect to external redundant power supply
Power Consumption
- 90 watts (max.)
Ventilation
- 40 x 40 X10 mm DC fans x 2
- 60 x 60 X18 mm DC fans x 1
Dimensions
- 441 x 207 x 44 mm
- 19-inch rack-mount width, 1 U height
Weight
- 3.15kg
Operating Temperature
- 0° to 40° C
Storage Temperature
- -25° to 55° C
Humidity
- 5% to 95% non-condensing
Emission (EMI)
- FCC Class A
- CE Class A
Safety
- CSA International
Ordering Information
Gigabit Stackable Layer 3 Switch
DGS-3324SR
- 24 10/100/1000BASE-T ports, 4 combo SFP (Mini GBIC) slots, redundant power support
Optional Gigabit Stacking Master Layer 3 Switch
DGS-3324SRi
- 24 10/100/1000BASE-T ports, 8 combo SFP (Mini GBIC) slots, redundant power support
Optional SFP (Mini GBIC) Transceiver
DEM-310GT
- SFP transceiver for 1000BASE-LX, single-mode fiber, max. distance 10km, 3.3V
DEM-311GT
- SFP transceiver for 1000BASE-SX, multi-mode fiber, max. distance 550m, 3.3V
DEM-314GT
- SFP transceiver for 1000BASE-LHX, single-mode fiber, max. distance 35km, 3.3V
DEM-315GT
- SFP transceiver for 1000BASE-ZX, single-mode fiber, max. distance 80km, 3.3V
Optional Redundant Power Supply
DPS-500
- 140-watt redundant power supply
DPS-800
- 2-slot redundant power supply chassis
DPS-900
- 8-slot redundant power supply chassis
