Indoor/Outdoor 5dBi Omni-Directional Ceiling Antenna

ANT24-0500

  • Product Status: End of Sale

Specs

Download the datasheet.

Electrical Specification

Frequency range
  • 2400 MHz - 2500 MHz
Gain
  • 5.0 dBi
VSWR
  • 2.0 : 1 Max.
Polarization
  • Linear, vertical

HPBW / horizontal
  • 360o

HPBW / vertical
  • 32o

Power handling
  • 20 W (cw)
Impedance
  • 50 Ohms
Connector
  • N female
Cable
  • 25 cm, RG58/U

Evironmental & Mechanical Characteristics

Survival wind speed
  • 180 km/hr

Temperature
  • - 40oC to +80oC

Humidity
  • 100% @ 25o C
Lightning protection
  • DC ground
Radome color
  • Gray-white
Radome material
  • Fiberglass
Radiator material
  • Micro striple line
Weight
  • 0.8kgw
Dimensions
  • 330 x 19 mm
