24-Port Fast Ethernet Unmanaged Desktop Switch

DES-1024D

  • Product Status: Live

The DES-1024D 24-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.


Download the datasheet.

Buy Now

With the D-Link 24-Port Fast Ethernet Unmanaged Switches, you can easily expand your business or home network by adding more computers and devices, each achieving speeds up to 200 Mbps per port in full-duplex mode. Quickly and securely connect employees working in small offices with one another and with all of the servers, printers, and other devices they use. High performance and reliable connectivity help speed file transfers and data processing, improve network uptime, and keep your employees connected and productive.

Expand and Upgrade Your Network

The DES-1024D switch offers an economical way for SOHO and small to medium businesses (SMB) to benefit from high-speed networking. It provides twenty-four ports for easy expansion of your network and a quick way to upgrade your network to Fast Ethernet connectivity. The switches speed file transfer times, improve slow and sluggish networks, keep your vital business applications available, and help your employees respond more quickly to customers and each other.

Conserve Energy

 The DES-1024D switch helps you conserve energy through IEEE802.3az EEE, which works when both the switch and its link partner are EEE-compliant devices. This power-saving feature automatically puts the switch into a low-power idle state when the switch utilization is zero, allowing you to lower your energy usage and save on your energy costs.

Designed with the Environment in Mind

 The DES-1024D switch uses recyclable packaging that helps reduce waste, complying with the WEEE directive. It’s innovatively designed  to run cool and quiet without sacrificing performance.

Type
Unmanaged
Number of ports
16 to 30 ports
Main type of ports
100BASE-TX Fast Ethernet
Switching capacity
4.8 Gbps
Fanless
Supported
D-Link Green
Supported
802.3az Energy-Efficient Ethernet support
Supported
Form Factor
Desktop
Rackmountable
Housing
Metal
MAC address
8K
Number of QoS queues per port
4
Version Date Type File Size
DES-1024D datasheet - PDF 0.84mb Download
Version Description Date Type File Size
Manual Manual 08/07/2002 PDF 0.11mb Download
Version Description Date Type File Size
Quick Installation Guide (English) - PDF 0.36mb Download
Version Description Date
DEU_AD_E1_CE_Doc CE Declaration 20/07/2012 Download
DEU_AD_D1_CE_Doc CE Declaration 13/07/2010 Download
DEU_AD_C4_CE_Doc CE Declaration 20/10/2006 Download
