Gigabit Desktop PCI Adapter

DGE-530T

  • Product Status: Live
  • One 1000 Mbps Gigabit port
  • Auto-negotiates port speed to 10 Mbps, 100 Mbps, or 1000 Mbps
  • Plug and play installation
  • Supports Jumbo Frames of up to 7 KB
  • ACPI 2.0 WOL Power Management
  • Supports 802.1Q VLAN tagging
Where to buy

Remote Management

The DGE-530T includes additional advanced features such as Advanced Power Management and Wake-on-LAN support. It also supports remote network boot using both PXE and RPL, allowing network administrators to boot the PC from anywhere on the network.

Versatility

The DGE-530T supports all major operating systems, guaranteeing compatibility with existing workstation and desktop environments. Its half-height form factor allows it to be used in low-profile cases for compact PCs. The card also has a diagnostic utility tool, simplifying troubleshooting.

Specification

Certifications
CE
Data Transfer Rate
Fast Ethernet: 100 Mbps half duplex, 200 Mbps full duplex
Ethernet: 10 Mbps half duplex, 20 Mbps full duplex
Gigabit Ethernet: Up to 2000 Mbps full duplex
Diagnostic LEDs
10/100/1000 Activity
10/100/1000 Link
Dimensions
120 x 120 x 18 mm (4.7 x 4.7 x 0.7 inches)
Interfaces
PCI half-height card suitable for low-profile cases
Maximum Power Consumption
3.42 W
Operating Humidity
10% to 90% non-condensing
Operating Temperature
0 to 40 °C (32 to 104 °F)
OS Support
Free BSD 7.x/8.x
Linux for Kernel 2.4.x/2.6.x/3.16
Mac OS X 10.4/10.5/10.6
Microsoft Windows Server 2000/2003/2008/2012
Microsoft Windows XP/Vista/7/8/8.1/10
NDIS 2 for DOS
Novell client for server 5.x/6.x
Novell client for server 5.x/6.x
Standards
ANSI/IEEE 802.3
IEEE 802.3, 802.3u, 802.3ab
IEEE 802.3x Flow Control
NWay auto-negotiation
PCI local bus 2.2, 2.3
Universal Bus Support 3.3 V / 5 V
Storage Humidity
5% ~ 95% RH
Storage Temperature
- 40 ~ 70 °C
Supported Functions
IEEE 802.1p Priority Queues
7 KB Jumbo Frames
Diagnostics utility
IEEE 802.1Q VLAN Tagging
Remote Boot (PXE)
Wake on LAN
Topology
Star
Weight
50 grams (1.76 ounces)
