1-Port GBIC Transceiver 1000BaseT, max. 100 m 3.3 V 5 V

DGS-711

  • Product Status (DEU Revision A): End of Life
Description

The DGS-711 is a high performance 1000BASE-T GBIC transceiver. Supporting full duplex, Gigabit speeds on standard CAT5 UPT cable for a distance up to 100m. The unit features a metal housing to reduce EMI and to increase durability. The DGS-711 is hot pluggable and is backed by a standard 3-year product warranty and free technical support. (Note: The DGS-711 Only Support 1000Mbps Full Duplex)

D-Link's new line of Gigabit Interface Converters (GBICs) and Small Form-Factors Pluggable (SFPs) transceivers represent an industry leading combination of performance and affordability. D-Link's new Gigabit transceivers are available in two form-factors: standard (GBIC) or (SFP)/mini-GBIC.

* Third-Party Devices Must Comply With specified Supported Industy-Standard Specifications

Specification

Download the datasheet.

Product/Performance Specifications

Data Rate Gigabit
  • 1.250Gbps (Bi-Directional)

Transmission Range

CAT5
  • 100m

Interface Options

Connector Type
  • RJ-45 Type

Standards

IEEE
  • 802.3ab

Operational Ranges

Support Voltage
  • 3.1-3.5V

Max Voltage
  • 6.0V

Max Current
  • 300mA

Physical Specifications

Dimensions (WxDxH)
  • 1.19x1.0x3.0 in

Safety Certifications and Environmental Information

Operating Temperature
  • 0°- 65° C (32° - 149° F)

Storage
  • -40° - 70° C (-40° - 158° F)

Operating Humidity
  • 10% to 85%

Warranty and Support Information

Warranty
  • Limited 3 Year Warranty for as long as the original customer/end user owns the product, (excluding power supplies and fans). Power supplies and fans carry a limited 3 year warranty.

Support
  • Free Technical

Ordering Information

DGS-711
  • 1000BASE-T CAT5 GBIC -(10Mbps and 100Mbps Speeds Are Not Supported)
